Ground Mounted PV Racking Systems

Ground Mounted PV Racking Systems

Ground Mounted PV Racking Systems are specially designed for large commercial and public utility power stations.

Description

Ground Mounted PV Racking Systems are specially designed for large commercial and public utility power stations. Labor cost and installation time can be reduced because of pre-assembled support.

Ground Mounted PV Racking Systems
Ground Mounted PV Racking Systems

Highly pre-assembled before shipment, save your onsite labor cost

Can be adjusted in both landscape and portrait direction, making the system being compatible in certain rugged terrain

Material    AL 6005-T5/SUS304/Q235B
Surface Treatment    Average Anodizing Coating Thickness≥ 12μm Average

Hot-galvanized Coating Thickness≥ 65μm

Panel Type
   Framed & Frameless
Wind Load    ≤60m/s
Snow Load   1.4KN/m2
 Panel Orientation    Landscape/Portrait
 Tilt Angle    0°~60°
Seismic Load    Lateral seismic factor: Kp=1;  seismic coefficient: Z=1; Use coefficient: I=1
Standards

   JIS C 8955 : 2017

   AS/NZS 1170

   DIN1055

   ASCE/SEI 7-05

   International Building Code: IBC 2009

 Warranty

  10years quality warranty, 25years life span warranty
